TRACK PRO（Black/Red）
-
TRACK PRO（Matte Black）
SPECIFICATIONS
- Price
- （完成車） ¥145,000 （税別）
- Sizes
- 49cm,52cm,54cm,56cm
- Color(s)
- Black/Red, Matte Black
- Main frame
- A6-SL super-butted 6066 aluminum
w/
aero-shaped downtube, hydroformed top tube
- Rear triangle
- A6-SL super-butted 6066 aluminum forged
Track dropout
w/ replaceable stainless axle interface
- Fork
- FC-770 Fuji straight-blade integrated carbon
w/
1 1/8” alloy steerer
- Crankset
- Driveline SQUARE-TYPE,1/2"*1/8"*48T
- Bottom bracket
- FSA, BB-7420
- Cassette
- 15T
- Chain
- KMC Z1 Wide
- Wheelset
- Oval Concepts 730 Track rim, 24/28h,
Formula sealed bearing track hub, bladed stainless spokes
- Tires
- Vittoria 700 x 23c, 60 tpi, folding
- Brake set
- Alloy dual pivot
- Brake levers
- Aero Road lever
- Headset
- FSA, 1 1/8” integrated
- Handlebar
- Oval Concepts 310 Ergo, 6061 alloy, 31.8mm clamp,
133mm drop, 4° sweep
- Stem
- Oval Concepts 717, 3D-forged 6061 stem body, +/-17
- Tape/grip
- Oval Concepts 300 bar tape, suede
- Saddle
- Oval Concepts X38 w/ pressure relief zone, cromo rail
- Seat post
- Oval Concepts, aero carbon
- Weight
- 8.2kg
GEOMETORY
| Size |
49cm |
52cm |
54cm |
56cm |
|---|
| Seat Tube, Center to Top |
470 |
500 |
520 |
540 |
|---|
| Top Tube, Effective |
510 |
525 |
545 |
560 |
|---|
| Head Tube |
100 |
110 |
120 |
135 |
|---|
| Seat Tube Angle |
75 |
75 |
74 |
74 |
|---|
| Head Tube Angle |
74 |
74 |
74.5 |
74.5 |
|---|
| Chainstay |
390 |
390 |
390 |
390 |
|---|
| Wheelbase |
934 |
950 |
956 |
971 |
|---|
| Fork Offset |
30 |
30 |
30 |
30 |
|---|
| Bottom Bracket Drop |
45 |
45 |
45 |
45 |
|---|
| Reach |
389 |
401 |
409 |
420 |
|---|
| Standover |
748 |
767 |
780 |
797 |
|---|
| Stem |
90 |
90 |
100 |
100 |
|---|
| Handlebar Width |
400 |
400 |
420 |
420 |
|---|
| Crank |
165 |
165 |
167.5 |
167.5 |
|---|
