Steven's voiceFUJI BIKE TECHNICAL DESIGN TEAM
-
シマノ新型105を搭載した完成車パッケージ。フレームはC10ハイモジュラスカーボンフレームにFC-440フルカー ボンフォーク仕様で、1.1から重量増となるも高剛性からのライドフィールは上位機種の1.1 に匹敵する。特にFC-440フルカーボンフォークは振動吸収性と路面追随性能が高い一方で、高速コーナーの安定性も高次元で実現。多数採用するovalconceptsパーツの中でもチェーンリングは冷間鍛造製法で作られており、変速性能はもとより耐久性、剛性の高さに定評がある。
SPECIFICATIONS
- Price
- (完成車)¥240,000 (税別)
- Sizes
- 46cm ,49cm ,52cm ,54cm ,56cm
- Color(s)
- Gray
- Main frame
- C10 high-modulus carbon, integrated head tube
w/ 1 1/2" lower, PF30 BB, double water bottle mounts - Rear triangle
- C10 high-modulus carbon oversized chainstays,
carbon dropout w/ replaceable hanger - Fork
- FC-440 full carbon w/ tapered carbon steerer
- Crankset
- Oval Concepts 300, forged 6066 arms,
Praxis rings, 52/36T - Bottom bracket
- Praxis PF30 conversion bottom bracket
- Front derailleur
- Shimano 105, braze-on mount
- Rear derailleur
- Shimano 105
- Shifters
- Shimano 105 Dual Control, 11-speed
- Cassette
- Shimano 105, 11-30T
- Chain
- KMC X11, 11-speed w/ MissingLink
- Wheelset
- Oval Concepts 327, 700c 20/24H rims
- Tires
- Vittoria Zaffiro Pro, 700 x 25c, 60tpi, folding
- Brake set
- Shimano 105
- Brake levers
- Shimano 105
- Headset
- FSA, 1 1/8" upper - 1 1/2" lower, integrated
- Handlebar
- Oval Concepts 310 Ergo, 6061 alloy, 31.8mm clamp,
133mm drop, 4° sweep - Stem
- Oval Concepts 313, 3D-forged 6061 stem body, +/-7°
- Tape/grip
- Anti-Slip Silicone
- Saddle
- Oval Concepts 438, steel rail
- Seat post
- Oval Concepts 905, carbon & alloy, 27.2mm diameter
- Weight
- 8.3kg
MATERIAL
- C10-High-Modulus Carbon
C15と共通の素材を使用しながら、素材強度に重点を置いて開発されたカーボンマテリアル。C15を上回る剛性を生かして、MTBやTRACKバイクなどトルク入力値や外的負荷が多くかかるスペシャリティバイクに採用されている。 - FC-330
超軽量C-15カーボンから作られるフルカーボン モノコックのフォーク。
GEOMETORY
Size | 46cm | 49cm | 52cm | 54cm | 56cm |
---|---|---|---|---|---|
Seat Tube, Center to Top | 420 | 450 | 480 | 500 | 520 |
Top Tube, Effective | 505 | 515 | 530 | 545 | 560 |
Head Tube | 100 | 110 | 130 | 150 | 170 |
Seat Tube Angle | 75 | 74.5 | 73.75 | 73.5 | 73 |
Head Tube Angle | 71 | 71.5 | 71.5 | 73 | 73 |
Chainstay | 405 | 405 | 405 | 405 | 405 |
Wheelbase | 974 | 975 | 979 | 974 | 983 |
Fork Offset | 52 | 52 | 52 | 43 | 43 |
Bottom Bracket Drop | 68 | 68 | 68 | 68 | 68 |
Reach | 372 | 374 | 376 | 381 | 385 |
Standover | 707 | 718 | 743 | 762 | 782 |
Stem | 80 | 90 | 90 | 100 | 100 |
Handlebar Width | 380 | 400 | 400 | 420 | 420 |
Crank | 165 | 170 | 170 | 172.5 | 172.5 |
