エントリー向けのハードテイルMTBが27.5インチホイール仕様となって復活。1.5DグレードはシマノDeoreのミックスコンポ仕様で油圧フォークサスペンション、油圧ディスクブレーキ搭載の本格スペックとなっている。
SPECIFICATIONS
- Price
- (完成車)¥82,000(税別)
- Sizes
- 13",15", 17"
- Color(s)
- Black/Silver
- Main frame
- Fuji A2-SL custom-butted alloy front triangle w/ PowerCurve down tube, oversized seat tube
- Rear triangle
- Fuji A1-SL alloy rear triangle w/ S-bend chainstays,
post disc mount, cold-forged dropout and replaceable hanger - Fork
- SR Suntour SF15-XCM-HLO-DS-27.5 w/ hydraulic lockout, 100mm travel
- Crankset
- Shimano Acera, alloy, 44/32/22T
- Bottom bracket
- VP-BC73, sealed cartridge bearing
- Pedals
- Resin platform
- Front derailleur
- Shimano Altus, 34.9mm
- Rear derailleur
- Shimano Deore, 9-speed
- Shifters
- Shimano Altus, Rapid Fire, 9-speed
- Cassette
- Shimano HG200-9, 11-34T, 9-speed
- Chain
- KMC Z99, 9-speed
- Wheelset
- Vera Terra DPD16 rims 32h, Formula DC-20LW front, Formula DC-22LW rear disc hubs, 14g stainless black spokes
- Tires
- Vera Eos, 27.5" x 2.2", 30tpi
- Brake set
- Tektro HD-M290, hydraulic disc, 180/160mm rotors
- Brake levers
- Tektro HD-M290, hydraulic disc
- Headset
- FSA NO 10, 1 1/8” semi-integrated, caged bearings
- Handlebar
- Oval Concepts riser bar, 6061 alloy, 15mm rise, 9 degrees sweep, 31.8mm clamp
- Stem
- Oval Concepts 313, 3D-forged 6061 stem body, +/-7 degrees
- Tape/grip
- Oval Concepts 400, dual density Kraton
- Saddle
- Oval Concepts 200, steel rail
- Seat post
- Oval Concepts, 6061 alloy, 31.6mm diameter
- Weight
- 14.4kg
MATERIAL
- A2-SLアルミニウム
軽量なだけでなく、厳選された素材を使用している。このパイプを使用したカスタム バテッド フレーム(強度が必要とされる場所、力を逃がす場所等必要に応じてパイプの肉厚を変えている)は軽量で高い耐久性を誇る。
GEOMETORY
Size | 13" | 15" | 17" |
---|---|---|---|
Seat Tube, Center to Top | 330.2 | 381 | 431.8 |
Top Tube, Effective | 535.4 | 545.4 | 580.4 |
Head Tube | 100 | 110 | 125 |
Seat Tube Angle | 73 | 73 | 73 |
Head Tube Angle | 70.5 | 70.5 | 70.5 |
Chainstay | 435 | 435 | 435 |
Wheelbase | 1025.9 | 1036.8 | 1072.1 |
Fork Offset | 42 | 42 | 42 |
Bottom Bracket Drop | 44 | 44 | 44 |
Standover | 750.5 | 773.3 | 802.8 |
Stem | 80 | 80 | 90 |
Handlebar Width | 680 | 680 | 710 |
Crank | 170 | 170 | 175 |
